FRONT & REAR INTERFACE for BMWs & MINI WITH THE FACTORY 6.5", 8.8", or 10.25" FULL COLOR LCD SCREEN THAT HAVE THE 4 PIN LVDS CONNECTION.
REQUIREMENTS
- MUST have the 4pin LVDS connector on backside of the factory screen.
- 6.5" , 8.8" , or 10.25" LCD screen.
- 4pin LVDS connection on the backside of the factory screen.
- FOR 100% COMPATIBILITY CHECK THE BACKSIDE OF THE LCD SCREEN FOR THE 4pin LVDS CONNECTOR.
WARNING ! There are several same year models that have different LVDS connections. Make sure to check the LVDS connection on the LCD screen to insure which interface you need.
Picture of the 4pin LVDS connector on the backside of the factory screen. (If the connector does not look exactly like the picture below, this module WILL NOT work.)
FEATURES
- Rear camera input.
- Front camera input.
- Dynamic Guide Lines (some vehicles may not support dynamic lines)
- 12 volt power output for the reverse camera.
- Automatic switching to rear-view camera input when in reverse.
- Forced front-view camera option
- picture(s) with factory parking sensor graphics
- Compatible with all factory video accessories.
- Module only
- Hardwire Installation required
