CAMERA INTERFACE PART#BMW12MOD2



REAR CAMERA INTERFACE for BMWs & MINI WITH THE FACTORY  6.5" , 8.8" , or 10.25" FULL COLOR LCD SCREEN THAT HAVE THE 6 PIN LVDS CONNECTION.





REQUIREMENTS
  • MUST have the 6pin LVDS connector on backside of the factory screen.
  • 6.5" , 7" , 8.8" , or 10.25 LCD screen.
  • 6pin LVDS connection on the backside of the radio.
  • FOR 100% COMPATIBILITY CHECK THE BACKSIDE OF THE LCD SCREEN FOR THE 6pin LVDS CONNECTOR.
  • I3 & I8 harness has to be extended from rear seat area to the screen.

Picture of the GUI and 6pin LVDS connector on the backside of the factory screen. (If your connector does not look exactly like the picture below, this module WILL NOT work.

WARNING ! There are several same year models that have different LVDS connections.  Make sure to check the LVDS connection on the LCD screen to insure which interface you need.

WARNING!  Some 2017 - UP models will have the "NEW" EVO system.  If the GUI looks like the picture below, this interface WILL NOT WORK.


FEATURES
  • Rear camera input.
  • Dynamic Guide Lines (some vehicles may not support dynamic lines)
  • 3 Audio/Video inputs
  • 12 volt power output for the reverse camera.
  • Automatic switching to rear-view camera input when in reverse.
  • Forced front-view camera option
  • Manual return from rear-view
  • picture(s) with factory parking sensor graphics
  • Compatible with all factory video accessories.
  • Module only
  • Plug & Play installation

VEHICLE FITMENT

BMW

MANUALS & UPDATES
  • None available
